Product Description
DESCRIPTION:
Model: Bendix ADB22
Vehicles: SAF-Holland SK7 Trailer Axles
• Brake Side: Right-Hand (RH)
• Caliper Type: Air disc with integrated 0° carrier
• Mounting Style: Bolt-on, axial mount (0° offset)
• Bolt Pattern: 4x M14 on standard ADB22 SK7 spacing
• Rotor Compatibility: 430 mm OD, 45 mm new thickness
• Brake Pad Compatibility: FP1369HK (Bendix ADB22 pad profile)
• Compatible Rotor: 430 mm OD, 45 mm new / 41.4 mm minimum
• Recommended Pin Kit: RAD10194
• Compatible Spring Brakes: RAD132352
• Technology/Performance: Bendix floating caliper, FMVSS 121 / CMVSS 121 compliant
• System Integrity: OEM replacement, certified new (no core charge)
Applications:
Engineered for 0° trailer axle configurations utilizing SAF-Holland SK7 systems. Designed for RH wheel-end installations on trailers equipped with Bendix ADB22 air disc brakes. Not suitable for non-SK7 platforms or LH installation.
CROSS-REFERENCE(S):
K012341, K012633K50, 5400101100, 5400101100K, 5400101100K50, RDB012341CX, RDB012341CRX, RDB012341CXCV, RDB012341CXHD, RDB012341CXXT, M012341X, BADC04R, 71113N4XXXN, GBADC3892, 22XK012341A, 1660407, 1660534, BR440045, 99B90035-1, CAB003R, BWK012341, PROADC2341, ADBHC2341N, RAD51830053X, FPK012341WC-G, FPK012341WCX
A cross-reference listing means this part may be a compatible replacement for these part numbers based on OEM or distributor data.
IMPORTANT INSTALLATION NOTES:
✔ Use only on SAF-Holland SK7 trailer axles with 0° ADB22 RH configuration
✔ Replace both LH and RH calipers at the same time for optimal performance
✔ Clean and prep the caliper mounting surface; ensure it is flat and free of corrosion.
✔ Mount the caliper and torque fasteners to OEM specifications.
✔ Turn the adjuster CLOCKWISE until the brake pads just contact the rotor (avoid over-tightening).
✔ Then turn COUNTER-CLOCKWISE 2 audible clicks to set clearance.
✔ Confirm system air pressure is between 100–120 psi.
✔ Block and secure wheels to prevent any movement.
✔ Depress the emergency brake release button on the dash to release spring brakes.
✔ Only after the wheels are secure and spring brakes are released should you proceed with caliper adjustment.
