Product Description
LEFT-HAND AIR DISC BRAKE CALIPER – ADB22 WITH 0° CARRIER (SK7)
DESCRIPTION:
Model: Bendix ADB22
Vehicles: Trailers with SAF-Holland SK7 axles using Bendix ADB22 calipers, left-hand side
• Brake Side: Left-Hand (LH)
• Caliper Type: Fixed air disc with integrated 0° carrier
• Mounting Style: Parallel to axle (0°), 4x M14 bolts
• Ports: Dual M12x1.0 inverted flare
• Brake Pad Compatibility: FP1369HK (Bendix ADB22 pad profile)
• Compatible Rotor: 430 mm OD, 45 mm new / 41.4 mm minimum
• Recommended Pin Kit: RAD10194
• Compatible Spring Brakes: RAD132352
• System Integrity: OEM replacement, certified new (no core charge)
Applications:
Designed for use on left-hand (LH) wheel ends of SAF-Holland SK7 trailer axles with Bendix ADB22 air disc brake systems and 0° carriers. Engineered to deliver reliable, high-performance braking on heavy-duty trailers. Replace LH and RH calipers together to maintain optimal braking balance and safety.
CROSS-REFERENCE(S):
K012342, K012634K50, 5400101200, 158.106001, FPK012342WC-G, GBADC3893, RDB012342CX, RDB012342CRX, RDB012342CXCV, RDB012342CXHD, RDB012342CXXT, M012342X, BADC04L, 71113N4XXXN, 22XK012342A, 1660408, 1660535, BR440046, 99B90035-2, CAB003L, BWK012342
A cross-reference listing means this part may be a compatible replacement for these part numbers based on OEM or distributor data.
IMPORTANT INSTALLATION NOTES:
✔ Use only on SAF-Holland SK7 trailer axles with 0° ADB22 LH configuration
✔ Replace both LH and RH calipers at the same time for optimal performance
✔ Clean and prep the caliper mounting surface; ensure it is flat and free of corrosion
✔ Mount the caliper and torque fasteners to OEM specifications
✔ Turn the adjuster COUNTER-CLOCKWISE until the brake pads just contact the rotor (avoid over-tightening)
✔ Then turn CLOCKWISE ¼ turn to set clearance
✔ Confirm system air pressure is between 100–120 psi
✔ Block and secure wheels to prevent any movement
✔ Depress the emergency brake release button on the dash to release spring brakes
✔ Only after the wheels are secure and spring brakes are released should you proceed with caliper adjustment
